High Quality DBC-B Type Crankshaft Pump

Home / Products / Plunger Pump / Commercial Crankshaft Pump / DBC Series Crankshaft Pump / DBC-B Type Crankshaft Pump
  • DBC-B Type Crankshaft Pump

    DBC-B

DBC Series Crankshaft Pump

DBC-B Type Crankshaft Pump

Code: DBC-B

Get a Quote +
PREV：DBC-A5 Type Crankshaft Pump
NEXT：DBC-C2 Type Crankshaft Pump

TECHNICAL DATA

Manifold: Brass forged
Crankcase: Die-cast aluminum alloy, anodized
Connecting Rod: One-piece aluminum alloy
Plunger: Ceramic coating, precision grinded
Packing: U-type, high-low dual pressure packing
Bearing: Ball and needle bearing
Crankshaft: Forged steel alloy, heat treatment, multiple process grinded
Head Port: Inlet 3/8", Outlet 1/2"
Unloader: Banjo bolt, trap type
Unloader Port: Inlet 3/4" (BSP or NH), Outlet 3/8" Quick Connect
Oil Bath Capacity: 450ml (half level of oil gauge)
Oil Type： 15W/40 Non-Detergent
Water Inlet Pressure: 0-50psi/3.5bar
Max Inlet Water Temp. ≤ 50°C/122°F

SPECIFICATION

MODEL: DBC-1507B

Max Flow(GPM, LPM) 2.7, 10.4
Max Pressure(PSI, BAR) 2700, 186
Power Input(HP) 4.0
Power Speed(RPM) 2860
Weight(KG) 7.7
Shipping Size(CM) 27.5x24.5x22.5


MODEL: DBC-1510B

Max Flow(GPM, LPM) 3.9, 14.8
Max Pressure(PSI, BAR) 2700, 186
Power Input(HP) 5.5
Power Speed(RPM) 2860
Weight(KG) 7.7
Shipping Size(CM) 27.5x24.5x22.5

MODEL: DBC-1514B

Max Flow(GPM, LPM) 2.8, 10.7
Max Pressure(PSI, BAR) 3400, 235
Power Input(HP) 5.5
Power Speed(RPM) 1450
Weight(KG) 7.7
Shipping Size(CM) 27.5x24.5x22.5

MODEL: DBC-1812B

Max Flow(GPM, LPM) 3.5, 13.3
Max Pressure(PSI, BAR) 3070, 212
Power Input(HP) 5.5
Power Speed(RPM) 1450
Weight(KG) 8
Shipping Size(CM) 27.5x24.5x22.5

MODEL: DBC-1814B

Max Flow(GPM, LPM) 4.1, 15.5
Max Pressure(PSI, BAR) 2600, 179
Power Input(HP) 5.5
Power Speed(RPM) 1450
Weight(KG) 8
Shipping Size(CM) 27.5x24.5x22.5

DIMENSION

COMPONENTS

  • MANIFOLD

    Brass Forged

  • CRANKCASE

    Aluminum Alloy

  • CRANKSHAFT

    Forged Steel Alloy

  • CONNECTING ROD

    Aluminum Alloy

  • PLUNGER

    Coating Ceramic

  • PACKING

    U Type Dual Seal

APPLICATIONS

  • PRESSURE WASHING
  • MISTING AND FOG MAKING
  • HOT WATERAPPLICATION
  • HIGH PRESSURECOOLANT
  • WATER TREATMENT
  • WATER JETCUTTING
